Specifications
Power Supply | 24VDC (12...28 V DC) |
---|---|
Dimensions, external (WxHxD) | 80x82x86 mm |
Sensor type | CO |
Measuring principle | Electrochemical |
Accuracy | ±3 % |
Measuring range, gas in air ppm | 0...300 ppm |
Output signal, gas in air | 4-20mA |
Lifetime sensor | ~ 2 years of age |
Response time | <35 s |
Protection class | IP56 |
---|---|
Ambient humidity (non-condensing) | 0...90 % RH |
Mounting | Wall |
Weight, incl. packaging | 0.19 kg |
Cable gland | M16x1.5 |
Material, housing | Polycarbonate (PC) |
