Specifications
Dimensions, external (WxHxD) | 90x255x85 mm |
---|---|
Max air velocity | 20 m/s |
Insertion length | 20...200 mm |
Time constant | 1.5 s at 10 m/s s |
Analogue output load impedance 0...10v | > 10 kΩ |
Analogue output load impedance 4...20mA | < 500 Ω |
Accuracy | Range 0.2...10 m/s ±(0.2 m/s + 3% of value) |
Response time | Selectable 0.7 or 4 s s |
Output | 0...10 V DC or 4...20 mA, selectable |
Protection class | IP65 |
---|---|
Storage temperature | -30...60 °C |
Mounting | Duct |
Cable gland | M16x1.5 |
Terminal type | Screw Terminal |
