VZO 8 OEM Aquametro Fuel / Oil Meter (4 - 135 Max 200 litre/hr)
€360,87 (€436,65 incl. VAT)
VZO 8 Contoil Fuel / Oil Meter (4 - 135 Max 200 litre/hr)
Blind unit, Pulse output only
1/4″ BSP
Product Code: 89771
Available on backorder
- 96.42% Has a good to very good experience with SENSORS.NL
- Personalized customer service
- Spacious assortment with a wide range of top brands
- Need an additional discount for quantities? Please contact us
SKU: VZO 8 OEM-RE0.0125
Categories: Aquametro, Fuel consumption, Flow Meters, Mechanical flowmeters
Tag: Aquametro
VZO 8 OEM-RE0.0125
Â
CONTOIL® Oil Volume Meter VZO 8 OEM-RE 0.0125
Ring piston meter for light fuel oil and diesel oil, without register unit, with Reed pulser, version for OEMs
Nominal diameter: DN 8 mm
Connection (at side): G1/4″ inside thread
Nominal pressure: PN 25 bar
Dimensions: Æ 74 x 46 mm
Installation position: horizontal / vertical
Temperature, max: 60°C
Measuring range (at visc. 1...20 mPa.s): 4...200 l/h
Max. continuous flow Qn: 135 l/h
Max. measuring deviation: 4...200 l/h ± 1%
Repeatability: ± 0.2%
With built-on RE Reed pulser
Contact load max: 230 V AC/DC, 50 mA, 3 VA
Pulse value: 0.0125 Litres Per Pulse
Weight | 10 kg |
---|
