Ultrasonic liquid level indicator Portamarine®(2290334-COPM)

Potamarine unit
Sensor with cable
20 mm extension rod
Ultrasonic gel
Wear-resistant carrying case
Calibration certificate
Ship Approval RINA

96.42% Has a good to very good experience with SENSORS.NL
Personalized customer service
Spacious assortment with a wide range of top brands
Need an additional discount for quantities? Please contact us

SKU: 2290334-COPM Categories: Coltraco Ultrasonics, Portable measurement, Gas bottle level, Level measurement, Ultrasonic & Radar

Coltraco's Portamarine is an ultrasonic liquid level indicator used for offshore fire prevention and inspections and especially popular for CO2 fire suppression systems aboard ships.

Type: 2290334-COPM
MSN: 6680-99-192-2735
IMPA MSG P/N: 652777

Dimensions	Height:98 mm (3.86 inches) Width:158 mm (6.22 inches) Depth:45.5 mm (1.80 inches) Weight:420 grams (14.82 ounces)
Accuracy	+/-1.5mm (1/8 inch)
Verifiable Agents	CO2, H20, FM-200™, NOVEC™1230, old Halons such as 1301 and 1211, FE-13™, FE-25™, FE-36™, HFC-225 & 2271
Sensor2	TX/RX Dry Sensor 14 mm diameter head Contained within a magnetized sensor applicator; Connected by BNC connectors to 1 m length co-ax cable. Mini Extension Rod Sensor 1 meter in length 24mm in diameter Connected by bnC connectors to 1 m length co-ax cable.
Power Supply	4 x AA 1.5V Batteries (battery life 10 hours)
Display	LCD Numeric Digital Display with LED Bar Graph
Operating Temperature	-20°C to +70°C (68°F to 158°F)Relative Humidity-5 % - 95 %
Certificates	Classification Society Approved- RINA CE ISO 19011 Registered
Classifications	IP Rating 65 NATO Stock Number: 6680-99-275-5292
Warranty	Main Unit:3 Years Warranty Sensor:1 Year Warranty Lifetime Customer Support
Package Contents	1 Potamarine unit 1 Wet Sensor 1 20 mm Extension Rod Ultrasonic Gel 1 Hard Wearing Carrying Case Calibration certificate
