MGI-250 F1″ BSP GEAR PULSER

€738,14 (€893,15 incl. VAT)

96.42% Has a good to very good experience with SENSORS.NL
Personalized customer service
Spacious assortment with a wide range of top brands
Need an additional discount for quantities? Please contact us

SKU: 32511 Categories: Gespasa, Meters Tag: Meters

MGI-250 1″ - Pulser

Pulser for its in-line assembly, making easier the exact information of the fluid management and control systems.

Technical data:

Flow (approx.):
- 10-250 l/min (diesel)
- 10-150 l/min (lubricant
Viscosity: 2-2000 cSt
Voltage: 28 VDC
Max. power: 8 W
Maximum current: 100 mA
Accuracy: ±0.5%
Maximum pressure: 45 bar
Min./max. temperature with Reeds: -10ºC / +90ºC
Two channels: 11 pulses per litre and channel
Inlet/outlet connection: F1″ or 1 1/2″ BSP (flange)
Housing and cover: Aluminum

Size and weight (approx.):

MGI-250 F1″

Dim.: 159x100x141 mm (length x width x height)
Weight: 2.3 kg

Rate this product

Product type:	Diesel Flow Meter
Vendor:	Gespasa Shop - International Fuel Equipment and Services
Product sku:	32511
Weight:	2.3 kg
