Specifications
Controller Type | Room Control |
---|---|
Power Supply | 230 V AC |
Mounting | Wall mount |
Display | Yes |
Power Supply | 230VAC (207...253 V AC 50/60Hz / ), 3.0 VA |
Dimensions, external (WxHxD) | 102x120x29 mm |
AI | 1 |
UI | 1 |
DI | 1 |
AO | 2 |
DO | 3 |
Color, cover | RAL9003 |
Change-over Automatic | Yes |
Outputs On/Off Valves | No |
Outputs Thermal/3 point | No |
Outputs 0...10V | Yes |
Protection class | IP20 |
---|---|
Ambient humidity (non-condensing) | 0...90 % RH |
Storage temperature | -20...70 °C |
Mounting | Room |
Weight, incl. packaging | 0.18 kg |
Analog inputs type (AI) | PT1000 |
Digital inputs type (DI). | Potential-free contact |
Digital outputs type (DO) | Relay 230V/3A |
Universal input type (UI). | PT1000 / DI |
Analog outputs type (AO) | 0-10V,1mA |
Accuracy, temperature 1 | ±0.5 °K @ 15...30 °C |
Material, housing | Polycarbonate, PC |
