Multigauge 5600 Ultrasonic Thickness Gauge

The Multigauge 5600 is a rugged and easy-to-use ultrasonic thickness gauge designed for the most common applications in industry and shipping. The bright full-color LCD display makes the gauge easy to read in all lighting conditions. The soft rubber housing provides additional protection as well as comfort.

This meter works with multiple echoes, allowing coatings up to 6 mm thick are automatically ignored - and even to 20 mm with the Coating Plus+ feature. Thanks to IPR (Intelligent Probe Recognition). automatically adjusts to the connected probe, and the AMVS (Automatic Measurement Verification System). guarantees reliable measurements even with corroded metal.

Key features

Ignores coatings up to 6 mm (standard) and up to 20 mm with Coating Plus+
AMVS - only reliable measurements are displayed
IPR - automatically recognizes connected probes
Large, full-color LCD screen
Rugged, protective rubber housing
Measurement hold function and echo strength indicator
Simple, menu-driven calibration
User-friendly operation with clear graphic menu
No zeroing required
Protective cover made of leather optionally available

Kit contents

Multigauge 5600 thickness gauge
Probe with probe cable
Spare membranes & membrane oil
Ultrasonic gel
15 mm test block
Diaphragm Key
Batteries
Manual
Calibration Certificate
Carrying bag

Specification	Value
Sound speed range	1000 m/s - 8000 m/s
Probes	Single crystal - 2.25 MHz, 3.5 MHz, 5 MHz
Measuring range	1 - 250 mm (depending on probe)
Probe sizes	6 mm, 13 mm, 19 mm
Measurement mode	Multiple echo
Solution	0.1 mm or 0.05 mm
Accuracy	± 0.1 mm or ± 0.05 mm
Display	Color LCD
Coating Detection	Up to 6 mm (standard), up to 20 mm (Coating Plus+)
Batteries	3 x AA alkaline or rechargeable NiMH/NiCD
Battery life	Up to 50 hours of continuous use
Dimensions	147 x 90 x 28 mm
Weight	325 g (including batteries)
Protection	IP65 enclosure, RoHS and WEEE compliant
Operating temperature	-10°C to +50°C
Storage temperature	-10°C to +60°C
