Müller Temperature Sensor Hygiene HART

Müller Temperature Sensor Hygiene HART - Image 2

Müller Temperature Sensor Hygiene HART

Price range: €174,14 through €235,94

Productinformatie en datasheets →

Output

Tube length (mm)

Process Connection

Electrical connection

Clear

Checking current stock status? Then contact us or use the live chat.

Waarom kopen bij Sensors.nl:

Uitstekend beoordeeld: 96.42% heeft een goede tot zeer goede ervaring
Persoonlijke klantenservice en advies
Extra korting bij grote aantallen mogelijk: Neem contact op

SKU: N/B Categories: Plug-in passive, Müller IE, Recorders active, Recorders passive

Beschrijving

technical features

Input: RTD Pt 100, Pt 1000
Measurement range: -50...+200 °C maximum
Accuracy transmitter: 0.3% of range
Accuracy RTD Pt100(0): Class A, Class AA, Class B
Output: 4...20 mA HART / RTD / CANopen
Resolution: 16 bit
Configuration: Via software (HART communication)
Electrical connection: M12 4-pole, M12 8-pole
Internal protection: Inside potted completely
Material: Stainless steel 1.4571
Protection class: At least IP65

5/5 - (1 stemmen)

Extra informatie

Weight	1 kg
Brand	Müller IE
Output	4 ... 20 mA HART, Pt100 2-wire, Pt100 3-wire, Pt1000 3-wire
Tube length (mm)	100, 110, 130, 150, 200, 400, 45, 50, 65, 85
Process Connection	G1/2" Hygienic
Electrical connection	M12x1, 4-pole, M12x1, 8-pole

Downloads

Product Documents

Data sheet

Data sheet
