Specificaties
Power Supply | 24VAC/DC (22…26 V AC 50Hz / 15…35 V DC), 2.5 VA |
---|---|
Dimensions, external (WxHxD) | 100x85x30 mm |
Display | Yes |
Supported protocols | Modbus |
Measuring range, temp | 0…50 °C |
Output temperature | Modbus |
Measuring range, gas in air | 0…2000 ppm |
Output signal, gas in air | Modbus |
Accuracy, gas in air | < ± (50 ppm + 2 % of the measured value) |
Long term stability | Typically 20 ppm / year |
Warm-up time | < 5 min |
Temperature dependance | Typically 5 ppm / K |
Protection class | IP30 |
---|---|
Ambient humidity (non-condensing) | 10…90 % RH |
Storage temperature | -25…60 °C |
Mounting | Room |
Accuracy, temperature 1 | ±0.2 °K @ 0…50 °C |
Terminal type | Screw Terminal |
Terminal wire size | 1.5 mm² |
Material, housing | Polycarbonate (PC) |
Colour, housing | Signal white RAL 9003 |
