Vision Flow Turbine meter | Vision2006, DN6 – range: 0,5 – 5 l/min

•   Low cost
•   Simple construction
•   Length 55 mm
•   High repeatability
•   Pulse output
•   Temperature range: -20 to +100C
•   Operating pressure: 25 bar

Electrical Connections:

• DIN connection, Micro-EN 60529
• AMP-Faston connection
• Cable, 3-core, 1m standard
• COIL output for display options

• Food: Coffee machines, vending machines, dispensing systems, bakery machines, and steamers
• Medical: Sterilizers, slide staining, dental water jets, and dialysis machines
• Chemical and Pharmaceutical: Dosing systems and bottling plants
• Industrial process: Cooling systems, washing machines and plants, dosing systems, water treatment units, filter monitoring systems, and solar plants
• Automotive: Fuel consumption measurement and fuel injection systems
